| Investment Casting | 1/4″ – 4″ | Sand Casting | 5″ – 8″ |
| Floating Type | 1/4″ – 2″ | Trunnion Type | 2-1/2″-12″ |
| Underwater Air Test Pressure | 80 – 100 psi | Temperature Range | -20°F to 600°F |
| End Type | Butt weld, Flanged, Socket weld, Threaded | Application | Fluid distribution and switching, Multi-station process control |
Available in Stainless Steel and Carbon Steel
With ISO 5211 direct mounting pad (1/4″ – 4″)
Available in L / T / X / I-Port
Available in 3 / 4 -way in block body type
Locking function
Adjusting stem packing
OPTIONS
• Automation applicable
• PTFE / PFA coating (40 – 70 um)
• TFM1600 / TFM4215 / PTFE
• PTFE Cavity Filler
• 180 degree operation stop plate
• Hastalloy C / Alloy 20 / Super Duplex / Monel
